Portable High Tonnage Jacks

Portable High Tonnage Jacks


Portable High Tonnage Jacks
Portable High Tonnage Jacks
Portable High Tonnage Jacks
Portable High Tonnage Jacks

Capacity 30 - 200 ton / Stroke 200 - 680 mm / Max. Working Pressure 700 bar

Features & Application :

» Compact & Portable, Steel Alloy Construction.
» Extension pieces / Bridges provided for additional reach.
» Electric / Pneumatic Motor (optional).
» Manual / Remote Pendant Control valve (optional).
» Suitable at Field & Dumper workshops for removal and fitment of Rear & Front    Wheels, Brakes overhaul, Final drives repairs, etc. of Heavy Mining Vehicles.

Capacity

(ton)
Stroke

(mm)
Model Motor Weight

(kg)
Stacking pads and
Rings
(mm)
Bridge Extension
190
mm
Bridge Extension
490
mm
30 200 OPJE 30-200 Electric 110.6 - - -
60 350 OPJA 60-350 Air 177.3 1145 750 1050
60 680 OPJA 60-680 Air 272.7 1475 1080 1380
60 350 OPJE 60-350 Electric 177.3 1145 750 1050
60 680 OPJE 60-680 Electric 272.7 1475 1080 1380
100 400 OPJA 100-400 Air 231.8 1007 790 1090
100 680 OPJA 100-680 Air 272.7 1307 1090 1390
100 400 OPJE 100-400 Electric 231.8 1007 790 1090
100 680 OPJE 100-680 Electric 272.7 1307 1090 1390
150 400 OPJA 150-400 Air 259.1 1017 800 1100
150 680 OPJA 150-680 Air 321.8 1312 1095 1395
150 400 OPJE 150-400 Electric 259.7 1017 800 1100
150 680 OPJE 150-680 Electric 321.8 1312 1095 1395
200 400 OPJA 200-400 Air 290.9 On Request 825 1125
200 680 OPJA 200-680 Air 375 On Request 1125 1425
